Thermaltake Commander C32 TG ARGB Edition Case

ERIES Commander

MODEL Commander C32 TG ARGB

CASE TYPE Middle tower

DIMENSION (H X W X D)462 x 233 x 507 mm
(18.2 x 9.2 x 20 inch)

NET WEIGHT 7.87 kg / 17.35 lb

SIDE PANEL 4mm Tempered Glass x1

COLOR Exterior & Interior : Black

MATERIALSPCC

COOLING SYSTEM Rear (exhaust) :
120 x 120 x 25 mm fan
(1000rpm, 16 dBA)
Front (intake) :
200x 200 x 30 mm ARGB fan x2
(800rpm, 29.2 dBA)

DRIVE BAYS
-ACCESSIBLE
-HIDDEN
-
3x 3.5“ or 2.5” (HDD Bracket); 2 x 2.5” (HDD Bracket)

EXPANSION SLOTS 7 + 2

MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)

I/O PORTUSB 3.0 x 2, HD Audio x 1, RGB Switch x 1

PSU Standard PS2 PSU (optional)

FAN SUPPORT Front:
3x 120mm, 2 x 140mm, 2 x 200mm
Top
2x 120mm, 2 x 140mm
Rear:
1x 120mm, 1 x 140mm

RADIATOR SUPPORT Front: 1 x 360mm, 1 x 280mm
Top: 1 x 240mm, 1 x 280mm
Rear: 1 x 120mm

CLEARANCECPU cooler height limitation: 180mm
PSU length limitation: 200mm
VGA length limitation: 310mm(With reservoir) 410mm(Without reservoir)
VGA width limitation(Vertically): 45mm
VGA height limitation: 110mm
RAM height limitation: 35mm (With 140mm radiator series) 50mm (With 120mm radiator series)
